SBS-ULTRA Diagnostic Tester

Product Details

Introducing the ULTRA Diagnostic Tester exclusively from SBS.

The new ULTRA is a cutting edge digital battery diagnostic tester meeting all IEEE/NERC Standard Recommendations for all stationary applications such as telecommunication's back up power, utility switching power, uninterruptible power systems (UPS) and more. The ULTRA can measure the accurate internal resistance (R), voltage (V), temperature (ºC) with the world's first ripple-removing algorithm (KR PAT No. 0494489) within a short time (3 seconds or less) during flotation charge.

The SBS-ULTRA Tests:

Internal Resistance (micro ohm)
Conductance (Siemens)
Voltage (V)
Internal Temperature (°C)
Each SBS-ULTRA Includes:

Soft Poly-Vinyl Bag (for storage or measurement)
Charger (for Li-ion Battery Pack)
Pin Probe (4-Point Pin type)
Clip Probe
Temperature Probe
Thermal Printer
Battery Trending Software FOR MULTI-USER enviorment
